SLG46583

9-GPIO, 4 ACMPs, 8-State ASM, I2C, 16 LUTs (max.), 5 CNT/DLY (max.), 9 DFF/LATCH (max.) and other Macrocells

The SLG46580/82/83 is a small, low power component commonly used to integrate mixed-signal functions under control of an asynchronous state machine. The user creates the circuit design by programming the one time Non-Volatile Memory (NVM) to configure the interconnect logic, the I/O Pins and the macro cells of the SLG46580/82/83. This highly versatile device allows a wide variety of functions and control logic to be designed within a very small, low power monolithic integrated circuit.

Four Analog Comparators (ACMP);

Voltage Reference (Vref) for ACMPs;

Analog Temperature Sensor;

Fifteen Combination Function Macrocells:

• Three Selectable DFF/Latch or 2-bit LUTs;
• Six Selectable DFF/Latch or 3-bit LUTs;
• One Selectable Pipe Delay or Ripple Counter or 3-bit LUT;
• Five 8-bit delays/counters or 3-bit LUTs;

Combinatorial Logic:

• One 4-bit LUT with two outputs;

Asynchronous State Machine:

• Eight States;
• Flexible input logic from state transitions;

Real Time Clock (RTC) Binary Counter;

Four Tri-Mode 150 mA LDO Regulators (for SLG46580):

• High Power Mode (HP Mode): 150 mA output with Quiescent Current at ~80 μA;
• Low Power Mode (LP Mode): 100 μA output with Quiescent Current at ~5 μA;
• Bypass Mode: Acts like a load switch;

Two Tri-Mode 300 mA LDO Regulators (for SLG46582):

• High Power Mode (HP Mode): 300 mA output with Quiescent Current at ~80 μA;
• Low Power Mode (LP Mode): 200 μA output with Quiescent Current at ~5 μA;
• Bypass Mode: Acts like a load switch;

One Tri-Mode 600 mA LDO Regulators (for SLG46583):

• 高功率模式(惠普模式):600毫安输出与很。惨死scent Current at ~60 μA;
• 低功耗模式(LP模式):400μ与Quies输出cent Current at ~5 μA;
• Bypass Mode: Acts like a load switch;

Serial Communications:

• I2C Slave Protocol Interface;

Programmable Delay with Edge Detector Output;

Additional Logic Functions:

• 2 Deglitch Filters with Edge Detectors;

Two Oscillators (OSC):

• Configurable 25 kHz/2 MHz;
• 2 kHz Low Power Oscillator;

Eight Byte RAM + OTP User Memory:

• RAM Memory space that is readable and writable via I2C;
• User defined initial values transferred from OTP;

POR.

Programmable Asynchronous State Machine

Logic & Mixed Signal Circuits

Highly Versatile Macrocells

Read Back Protection (Read Lock)

Four 150 mA LDO Regulators (SLG46580)

Two 300 mA LDO Regulators (SLG46582)

One 600 mA LDO Regulators (SLG46583)

I2C Interface

2.5 V (±8%) to 5 V (±10%) Supply

Operating Temperature Range: -40°C to 85°C

RoHS Compliant / Halogen-Free

SLG46583V: STQFN-20 (2.0 x 3.0 x 0.55 mm, 0.4 mm pitch)

The product ID suffix indicates the package style.
