SLG46537.

18-gpio，4 acmps，8状态ASM，I2C，17个LUT（最大值），7个CNT / DLY（MAX。），8个DFF / LATCH（MAX。）和其他宏小区

The SLG46537V/M provides a small, low power component for commonly used mixed-signal functions. The user creates their circuit design by programming the one time Non-Volatile Memory (NVM) to configure the interconnect logic, the I/O Pins and the macro cells of the SLG46537V/M. This highly versatile device allows a wide variety of mixed-signal functions to be designed within a very small, low power single integrated circuit.

Four Analog Comparators (ACMP);

两个电压参考（VREF）;

Seventeen Combination Function Macrocells:

• Three Selectable DFF/Latch or 2-bit LUTs;
• 一个可选的连续DFF /闩锁或3位LUT;
• 四个可选择的DFF /闩锁或3位LUT;
• One Selectable Pipe Delay or 3-bit LUT;
• 一个可选择的可编程模式生成器或2位LUT;
• 五个8位延迟/计数器或3位LUT;
• Two 16-bit delays/counters or 4-bit LUTs;

异步状态机：

• 八个州;
• 来自状态转换的灵活输入逻辑;

串行通信：

• I2C Protocol compliant;

管道延迟 - 16级/ 3输出（组合功能宏子的一部分）;

Programmable Delay;

Additional Logic Functions – 2 Deglitch Filters with Edge Detectors;

两个振荡器（OSC）：

• 可配置25 kHz / 2 MHz;
• 25 MHz RC振荡器;

Crystal Oscillator;

上电复位（POR）;

八个字节RAM + OTP用户内存：

• RAM存储空间可通过I2C可读和可写;
• 用户定义了从OTP传输的初始值;

Analog Temperature Sensor.

Logic & Mixed Signal Circuits

高度通用的宏小胶质

读取保护（读锁）

1.8 V（±5％）至5 V（±10％）供应

Operating Temperature Range: -40°C to 85°C

RoHS Compliant / Halogen-Free

个人计算机和服务器

PC外围设备

消费类电子产品

Data Communications Equipment

Handheld and Portable Electronics

SLG46537.V: STQFN-20 (2.0 x 3.0 x 0.55 mm, 0.4 mm pitch)

SLG46537.M：MSTQFN-22（2.0 x 2.2 x 0.55 mm，0.4 mm间距）

The product ID suffix indicates the package style.
