DA14585 Development Kit-Basic
Develop and create more advanced connected applications
This Development Kit gives you all the flexibility you need to develop your product with confidence, creating more advanced connected applications with the smallest footprints and power budgets. At the core of this development kit is our SmartBond™ DA14585. It is the smallest, lowest power and most integrated Bluetooth System-on-Chip solution currently available. And this versatile SoC brings Bluetooth 5.0 functionality to our well-known DA1458x family. The DA14585 hardware development environment is available as a starter kit, containing motherboard and daughterboard. Additional separate daughterboard kits can be ordered.
The motherboards gives access to all of the package’s GPIOs and the on-board SEGGER chip provides the complete debugging capability while dedicated on-board circuitry allows you, in combination with our complete software environment SmartSnippets™, to profile and fine tune the power consumption of your application to get the most out of the DA14585’s advantages.
Features
USB/UART/SWD interface
GPIO connections
SPI-Flash-memory
The mounted DA14585 device
PCB antenna
Content
Bluetooth low energy basic board
Mini USB-cable
Coin cell battery (CR2032)
SmartBond™ DA14585 Development Kit Basic
In this video, you can see how to set up the DA14585 Development Kit Basic and view some of it’s important features.
Buy now
| Product | Shop | ||||
|---|---|---|---|---|---|
| DA14585 Development Kit-Basic - DA14585-00ATDEVKT-B | Digikey | Mouser | Avnet Silica | Avnet US | Farnell |
