Dialog’s latest Configurable Mixed-signal Integrated Circuit (CMIC) features configurable logic and includes 4 high-drive outputs ideal for 12 volt motor applications
London, United Kingdom–June 10, 2020–雷竞技电竞平台对话框的半导体公司(XETRA:DLG公司), a leading provider of battery management, AC/DC power conversion, Wi-Fi, Bluetooth®低能耗和工业集成电路，今天宣布SLG47105，它的第一个电机驱动CMIC，提供可配置逻辑和可配置模拟与高压输出的独特优势，所有封装在一个微小的2 x 3毫米QFN封装。
SLG47105加入了Dialog广泛采用的GreenPAK产品系列，为希望集成数字和模拟系统功能的设计师提供了更具成本效益的一次性NVM可编程选项，同时最大限度地减少了消费类和工业电机应用的元件数量、板空间和功耗。雷竞技安卓下载
新设备能够驱动两个有刷直流电机、一个步进电机、螺线管或任何其他负载，每个输出需要高达1.5A RMS电流，工作电压高达13.2V。除了超温、欠压和过流保护等标准保护功能外，SLG47105还包括可配置的数字和数字电路模拟资源允许用户创建定制的保护和电机控制方案，具有电流或电压调节、失速检测或软电机启动，以实现更高的系统可靠性和更高效的电池使用。
The SLG47105 includes low power consumption functions including internal voltage references, power-on reset, an oscillator and more advanced digital resources, like Pulse Width Modulators. The current consumption in standby mode for the entire chip is as low as 70nA, which guarantees a longer battery life and helps to reduce the overall solution price, BOM, PCB size and can achieve a lower overall system current consumption versus more discrete solutions used in the industry today.
Dialog可配置混合信号业务部门营销副总裁John McDonald说：“将高电压功能添加到我们的GreenPAK产品系列将为电机领域带来巨大机遇。”。“随着近50亿个CMIC的出货量，这一新产品将进一步加速GreenPAK在更广泛的应用中的采用，包括刷式和步进电机，从工业到消费电器和智能家居。”雷竞技安卓下载
In addition to the introduction of the SLG47105, Dialog is also releasing a new update for the GreenPAK Designer software package. Prior releases have used the GreenPAK Designer software to configure, optimize, simulate, test and evaluate GreenPAK designs. Now, GreenPAK Designer Software contains simulation capabilities to incorporate external components, ranging from passive components like shunt resistors to more complex devices like motors, which will further reduce development time and simplify the design process across the entire GreenPAK portfolio.
SLG47105目前正在取样，将于2020年下半年投产。通过Dialog的GreenPAK在线商店，SLG47105现在可以获得一个评估板，其中包括一个有刷电机和步进电机。
有关SLG47105的更多信息，请访问：www.wsdof.com/products/slg47105
